Description
The SC Series Jaw Crusher serves as the vital backbone for global aggregates production, heavy mining operations, and material recycling. Backed by a proven track record of over 13,000 successful installations since 1975, this robust series delivers peak productivity at the lowest possible cost per ton. Whether you are processing dense basalt or heavy-duty recycled concrete, these industrial crushers consistently outperform the competition in the harshest environments.
TECHNICAL SPECIFICATIONS
| MODEL | FEED OPENING, WIDTH X DEPTH*** | CAPACITY UP TO, SCALPED FEED, MAXIMUM SETTING | CAPACITY UP TO, NON-SCALPED FEED, MAXIMUM SETTING | POWER | SPEED |
|---|---|---|---|---|---|
| SC63 | 630 incógnita 440 mm (25″x 17″) | 45 kilovatios (60 hp) | 340 rpm | ||
| SC80 | 800 incógnita 510 mm (32″ x 20″) | 335 Mtph (370 Stph) | 514 Mtph (575 Stph) | 75 kilovatios (100 hp) | 350 rpm |
| SC96 | 930 incógnita 580 mm (37″ x 23″) | 390 Mtph (430 Stph) | 592 Mtph (662 Stph) | 90 kilovatios (125 hp) | 330 rpm |
| SC100 | 1000 incógnita 760 mm (39″x 30″) | 110 kilovatios (150 hp) | 260 rpm | ||
| SC106 | 1060 incógnita 700 mm (42″ x 28″) | 500 Mtph (560 Stph) | 760 Mtph (850 Stph) | 110 kilovatios (150 hp) | 280 rpm |
| SC3054 | 1375 incógnita 760 mm (54″x 30″) | 160 kilovatios (200 hp) | 260 rpm | ||
| SC116 | 1150 incógnita 800 mm (45″x 32″) | 132 kilovatios (170 hp) | 260 rpm | ||
| SC110 | 1100 incógnita 850 mm (43″x 33″) | 160 kilovatios (200 hp) | 230 rpm | ||
| SC120 | 1200 incógnita 870 mm (47″ x 34″) | 540 Mtph (600 Stph) | 800 Mtph (880 Stph) | 160 kilovatios (200 hp) | 230 rpm |
| SC125 | 1250 incógnita 950 mm (49″x 37″) | 160 kilovatios (200 hp) | 220 rpm | ||
| SC130 | 1300 incógnita 1000 mm (51″ x 39″) | 831 Mtph (915 Stph) | 1 267 Mtph (1 416 Stph) | 160 kilovatios (200 hp) | 220 rpm |
| SC140 | 1400 incógnita 1070 mm (55″x 42″) | 200 kilovatios (300 hp) | 220 rpm | ||
| SC145 | 1400 incógnita 1100 mm (55″x 43″) | 200 kilovatios (300 hp) | 220 rpm | ||
| SC150 | 1400 incógnita 1200 mm (55″ x 47″) | 880 Mtph (970 Stph) | 1 319 Mtph (1 474 Stph) | 200 kilovatios (300 hp) | 220 rpm |
| SC160 | 1600 incógnita 1200 mm (63″ x 47″) | 1 145 Mtph (1 260 Stph) | 1 909 Mtph (2 133 Stph) | 250 kilovatios (350 hp) | 220 rpm |
| SC200 | 2000 incógnita 1500 mm (79″ x 59″) | 1 435 Mtph (1 575 Stph) | 2 462 Mtph (2 752 Stph) | 400 kilovatios (500 hp) | 200 rpm |
TECHNICAL SPECIFICATIONS
| Model | SC63 | SC80 | SC96 | SC100 | SC106 | SC3054 | SC116 | SC110 | SC120 | SC125 | SC130 | SC140 | SC145 | SC150 | SC160 | SC200 | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Feed inlet width (mm) | 630 | 800 | 930 | 1000 | 1060 | 1375 | 1150 | 1100 | 1200 | 1250 | 1300 | 1400 | 1400 | 1400 | 1600 | 2000 | |
| Feed inlet depth(mm) | 440 | 510 | 580 | 760 | 700 | 760 | 800 | 850 | 870 | 950 | 1000 | 1070 | 1100 | 1200 | 1200 | 1500 | |
| Fuerza(kilovatios) | 45 | 75 | 90 | 110 | 110 | 160 | 132 | 160 | 160 | 160 | 160 | 200 | 200 | 200 | 250 | 400 | |
| Rotational speed (rpm) | 340 | 350 | 330 | 260 | 280 | 260 | 260 | 230 | 230 | 220 | 220 | 220 | 220 | 220 | 220 | 200 | |
| Product Granularity (mm) | Tight edge discharge port (mm) | Capacidad (tph) | |||||||||||||||
| 0-30 | 20 | ||||||||||||||||
| 0-35 | 25 | ||||||||||||||||
| 0-45 | 30 | ||||||||||||||||
| 0-60 | 40 | 40-45 | 65-85 | ||||||||||||||
| 0-75 | 50 | 55-60 | 80-95 | ||||||||||||||
| 0-90 | 60 | 65-70 | 95-125 | 120-155 | |||||||||||||
| 0-105 | 70 | 80-90 | 115-150 | 140-180 | 150-210 | 155-200 | 240-310 | 170-220 | 190-250 | 205-275 | |||||||
| 0-120 | 80 | 95-105 | 130-170 | 160-210 | 170-225 | 175-230 | 270-350 | 190-250 | 210-275 | 230-300 | |||||||
| 0-135 | 90 | 110-120 | 150-195 | 180-235 | 190-245 | 200-260 | 295-385 | 215-280 | 235-305 | 255-335 | |||||||
| 0-150 | 100 | 120-135 | 165-215 | 200-260 | 215-280 | 220-290 | 325-425 | 240-310 | 255-330 | 275-360 | 290-380 | 270-369 | |||||
| 0-185 | 125 | 210-275 | 250-325 | 265-345 | 280-365 | 390-510 | 295-385 | 310-405 | 335-445 | 350-455 | 325-446 | 385-500 | 400-520 | 405-525 | |||
| 0-225 | 150 | 250-325 | 300-390 | 315-410 | 335-435 | 460-600 | 350-455 | 370-480 | 400-525 | 410-535 | 380-523 | 455-590 | 470-610 | 480-620 | 520-675 | ||
| 0-260 | 175 | 290-380 | 350-455 | 370-480 | 390-510 | 530-690 | 405-525 | 425-550 | 460-610 | 470-610 | 435-600 | 520-675 | 540-700 | 545-705 | 595-775 | 760-990 | |
| 0-300 | 200 | 420-545 | 445-580 | 600-780 | 460-600 | 480-625 | 525-685 | 530-690 | 490-677 | 590-765 | 610-795 | 620-800 | 675-880 | 855-1110 | |||
| 0-340 | 225 | 590-770 | 545-754 | 655-850 | 680-885 | 690-890 | 750-975 | 945-1230 | |||||||||
| 0-375 | 250 | 650-845 | 600-831 | 725-945 | 750-975 | 790-1025 | 825-1070 | 1040-1350 | |||||||||
| 0-410 | 275 | 820-1070 | 900-1170 | 1130-1470 | |||||||||||||
| 0-450 | 300 | 980-1275 | 1225-1590 | ||||||||||||||
| The crusher output figures above represent values for an average specific gravity of 2.7 t/m³, assuming the feed can smoothly enter the crushing chamber without clogging, and using the smaller value when fine material smaller than the discharge opening is removed, and the larger value when fine material is present. Output may vary depending on the feeding method and material properties such as particle size distribution, moisture and mud content, bulk density, and crushability. | |||||||||||||||||
FEATURES
1. Proven Reliability of the SC Series Jaw Crusher
Reliability is backed by a proven track record rather than mere claims. Thousands of global operators rely on the SC Series for its exceptional versatility and rugged durability. While engineered specifically to fracture the toughest ores, it performs with equal efficiency on softer materials. Available across stationary, mobile, and portable configurations, it adapts effortlessly to precise site requirements.
2. Uncompromised Structural Integrity
Conventional welding is replaced with an advanced pinned and bolted, non-welded frame architecture. This innovative engineering delivers superior fatigue strength, allowing the machinery to endure intense, high-stress cycles. Enhanced by proprietary proprietary alloy composition and a structural cellular framework, the chassis achieves structural integrity far surpassing traditional welded designs.
- Non-welded frame architecture ensuring maximum resistance to structural fatigue.
- Premium-grade components sourced from world-class global suppliers.
- Advanced casting design for long-term operational durability.
3. High Production and Superior Reduction Ratio
The SC Series Jaw Crusher incorporates an aggressive pitman motion paired with an extended stroke at the lower cavity. An expansive feed opening enables large, restricted rocks to enter smoothly, while a steep nip angle accelerates material flow and minimizes wear on the jaw dies. This synchronized dynamic maximizes both overall throughput and reduction ratios across every application.
4. Streamlined Installation and Operation
A modular engineering approach reduces setup times and minimizes on-site installation costs. These crushers can be assembled within days, removing the need for extensive field fabrication. Built-in automation features enable remote monitoring and adjustment of feeders, crushers, and downstream conveyors, fostering a safer and more productive working environment.
- Remote telemetry for real-time performance tracking and tuning.
- Accessible wear components designed for rapid field replacement.
- Modular assembly framework simplifying transport and deployment.
5. Customizable Operational Options
Tailor your equipment configuration to meet exact operational demands. From protective flywheel and drive guards that safeguard work crews to space-saving integrated motor bases, the SC Series provides a comprehensive ecosystem of functional upgrades.
- Standardized lifting apparatus for safe jaw die and cheek plate handling.
- Optional maintenance service platforms ensuring secure operational access.
- Advanced automation control packages for streamlined plant integration.
SC SERIES JAW CRUSHER PARTS AND SERVICES
Jaw Crusher Wear Parts
Engineered to maximize crushing efficiency while eliminating costly, unexpected downtime, SUNWE provides durable, high-performance wear components. We offer a comprehensive inventory of replacement and wear parts designed to seamlessly fit not only our own equipment (including legacy models formerly under Metso) but also alternative leading jaw crusher brands.
Chamber Expert Service: Maximize Operational Profitability
Aggregates producers continually seek to extract maximum economic value from their capital assets. Through our specialized Chamber Expert Service, we deliver precision-engineered wear solutions customized to specific reduction needs. Our core objective is to help operations achieve superior throughput, optimized product gradation, and enhanced energy efficiency.
Maximize Your Crushing Circuit Efficiency
Unlock the ultimate production potential of your circuit with expert technical support. Whether the priority is mitigating unplanned downtime, expanding output capacity, or lowering the total cost per ton, we supply targeted strategic assistance. Our solutions also prioritize environmental sustainability, ensuring strict adherence to final size-reduction targets.
Precision Maintenance & Repair Solutions
While heavy machinery naturally experiences performance wear over time, proactive maintenance and professional refurbishment can effectively reverse wear indicators and maintain production schedules. SUNWE supports every stage of the equipment lifecycle, ranging from urgent emergency repairs to comprehensive, turnkey project management solutions.
